API 650 Vertikal-Schwimmdach-Tanks

Product Structure

• Tiered Cylindrical Shell: A high-strength body composed of multiple horizontal rings of precision-welded steel plates for uniform pressure distribution.

• Reinforced Fixed Roof: A heavy-duty conical or dome-shaped roof designed to protect contents from environmental elements and prevent vapor loss.

• External Safety Infrastructure: Includes perimeter guardrails on the roof and integrated spiral or straight-run staircases for safe operator access.

• Heavy-Duty Foundation Base: A reinforced concrete or asphalt sand pad that provides a stable, level surface for the massive weight of the tank.

• System Nozzles & Manways: Large-diameter access manways at the base and various flanged ports for filling, draining, and sensor integration.

Product Advantages

• Massive Storage Efficiency: Vertical orientation allows for the storage of millions of liters of fluid while occupying a relatively small geographical footprint.

• Superior Structural Durability: Built with high-tensile carbon steel, featuring multi-layer welding to withstand internal hydrostatic pressure and external wind loads.

• Site-Specific Customization: As these tanks are field-erected, they can be customized in height and diameter to fit the specific constraints of your industrial site.

• Maintenance Accessibility: Integrated staircases and top-level walkways allow for easy periodic inspections and maintenance of sensors and valves.

• Corrosion Protection: Can be finished with specialized internal linings and external epoxy coatings to handle aggressive chemicals and outdoor exposure.

Material & Specifications

Feature	Specification
Primary Material	Carbon Steel (Q235B / Q345R) or Stainless Steel (Optional)
Construction Method	Field-Welded / Site-Erected
Capacity Range	100m³ to 50,000m³+ (Fully Customizable)
Surface Treatment	Internal Epoxy Lining / External Polyurethane Coating
Safety Compliance	API 650, GB 50341, or equivalent international standards

Technical Parameters

• Working Temperature Range: -40°C to +90°C (Insulation options available for extreme temperature control).

• Auslegungsdruck: Atmospheric pressure (Standard) to low-pressure variants.

• Seismic Rating: Custom-engineered to meet local seismic and wind load requirements.

Anwendungsszenarien

• Petroleum & Oil Refineries: Bulk storage of crude oil, diesel, gasoline, and heavy fuel oils.

• Chemical Plants: Containment of raw liquid materials, finished chemical products, and solvents.

• Municipal Water Treatment: Large-scale reserves for fire-protection water, treated wastewater, or potable water.

• Agricultural Bulk Storage: Storing large volumes of liquid fertilizers or irrigation water.

• Energy & Power Stations: Management of demineralized water and auxiliary fuel storage for power generation.
